FEATURES
Reliable Foton M5 Chassis Performance
The Foton M5 7CBM Water Sprinkler Truck is built on the robust BJ1046V9JDA-51 light-duty chassis, offering excellent load-bearing capacity and durability. With a 3360mm wheelbase, this water sprinkler truck provides outstanding maneuverability, making it perfect for narrow urban roads and confined working environments. The reinforced double-layer frame structure ensures long-term reliability even under continuous operation.
Large Capacity 15CBM Water Tank
With a 15,000-liter tank capacity, the truck supports long working hours without frequent refilling. The Zhonglian tank structure ensures durability, corrosion resistance, and reliable performance in different environments.
High-Quality 7CBM Water Tank Structure
The 7 cubic meter water tank is made of premium Q235 carbon steel, ensuring corrosion resistance and structural strength. Inside the tank, a butterfly-shaped anti-wave plate reduces water impact during driving, improving safety and stability. The tank is securely mounted using four U-bolts, ensuring durability and easy maintenance. This design makes the truck ideal for water transportation, road spraying, and irrigation applications.
Multi-Function Sprinkler System with Optional Fog Cannon
This 7CBM water sprinkler truck comes with a standard sprinkler system for front flushing, rear spraying, and side watering. It supports multiple functions such as road cleaning, dust suppression, and green belt irrigation. Additionally, a fog cannon can be installed optionally to extend spraying range and enhance dust control efficiency, making it suitable for construction sites, mining areas, and urban environmental protection projects.
SPECIFICATIONS
| Item | Specification |
|---|---|
| Chassis Model | BJ1046V9JDA-51 |
| Wheelbase | 3360 mm |
| Overall Dimension | 5995 × 2090/2050 × 2900 mm |
| GVW | 4495 kg |
| Curb Weight | 3630 kg |
| Tank Volume | 7 m³ |
| Tank Material | Q235 Carbon Steel |
| Tire Specification | 7.00R16 |
| Fuel Type | Diesel |
| Emission Standard | Euro VI |
| Engine Model | Q25-152E60 |
| Engine Power | 150 / 152 HP |
| Transmission | 5-speed / 8-speed |
| Cab Width | 1850 mm |
| Brake System | Air Brake |
| Axle Load | Front 2.2T / Rear 4.5T |
| Optional | Fog Cannon |
