FEATURES
High-Strength 8000L Fuel Tank: Manufactured from carbon steel, stainless steel, or aluminum alloy with anti-corrosion treatment and strict welding standards.
Efficient Pumping System: This fuel tank truck is equipped with a self-priming fuel pump, a flow meter, a fuel hose, and a nozzle for fast and accurate refueling.
Comprehensive Safety Protection: The aircraft refuelling truck includes emergency shut-off valve, anti-overflow device, grounding system, pressure relief valve, and fire extinguisher.
Reliable Chassis Selection: The 8000L aircraft refuelling truck can be mounted on light-duty, medium-duty, or heavy-duty truck chassis from well-known brands, such as Dongfeng or Howo.
SPECIFICATIONS
BASIC INFORMATION | |
Product Model | 8000L Aircraft Refuelling Truck |
Overall Dimension | 6950×2400×2800 mm |
Tank Capacity | 8000 L |
GVW | 18000 kg |
CHASSIS | |
Model | Dongfeng |
Wheelbase | 3800 mm |
Axle loading (front / rear) | 4360/7590 |
Max Driving Speed | 80 km/h |
Tire | 215/75R17 16PR |
BULK TANK | |
Material | Q235B carbon steel (optional) |
Effective Tank Volume | 8000 L |
Optional Equipment | Ladder/Guard/Fender/Loading / Unloading Hose |
The above mentioned figures are approximate.
