FEATURES
1. Heavy-Duty Load Capacity
• Rated loading capacity up to 60 tons
• Suitable for heavy machinery and oversized cargo
2. Stable & Safe Operation
• JOST 28-ton landing gear for secure parking
• Thickened 4 mm rear bumper improves safety
3. Reliable Axle & Suspension System
• 3 × TITAN axles, 13 tons per axle
• Mechanical suspension with 10-layer leaf springs
• Strong shock absorption and load stability
4. Reinforced High-Strength Frame
• High-strength steel chassis
• 160mm side beams
• Long service life under harsh working conditions
SPECIFICATIONS
BASIC INFORMATION | |
Model | |
Overall Dimensions (mm) | 12500x2500x1530 |
Payload (kg) | 60000 |
CHASSIS | |
Side Beam | 160 mm |
Axle | 3 axles |
Axle Loading Capacity | 13 ton |
RUNNING SYSTEM | |
Tyres | 12 units |
Rims | 12 PCS Steel |
Suspension | Mechanical Suspension |
Leaf Spring | 10 layers |
BRAKING SYSTEM | |
Brakes | WABCO |
Brake Chambers | T30/30 spring brake chamber |
Emergency Valve | WABCO |
Air Tanks | YES |
The above mentioned figures are approximate.
