FEATURES
High-Capacity Tank System
The Liquid Supply Truck is equipped with a 15,800L total capacity tank (effective volume 15,070 L), designed for handling various well-servicing fluids. Its cylindrical design (5600×2300×1600 mm) ensures maximum fluid storage while maintaining vehicle stability during transportation.
Reliable Diesel Engine Options
Multiple diesel engines are available, offering power ranges from 162 kW (220 PS) to 220 kW (299 PS), all meeting China National VI standards. These engines provide consistent performance, high torque, and fuel efficiency for demanding field operations.
Safety and Control Systems
Standard ABS from ZF Commercial Vehicle Systems (Qingdao) ensures safe braking under all conditions, with optional EBS systems for enhanced electronic brake control. Additional safety features include side and rear protective bolts and reflective markings from 3M and Tongming.
Durable Structure and Design
The chassis and tank are designed for heavy-duty operations, with Q235B carbon steel protective components, bolt-connected panels, and rear protection at 490 mm ground clearance. Optional speed-limiting devices help maintain operational safety, while the 15800L Liquid Supply Truck supports up to 3 passengers in the cabin.
SPECIFICATIONS
Parameter | Description | |
Overall Dimension (L×W×H) | 8200 × 2500 × 3250 mm | |
Tank Volume | 15,800 L (Total), 15,070 L (Effective) | |
Tank Dimension (L×Long Axis×Short Axis) | 5600 × 2300 × 1600 mm | |
Gross Vehicle Weight | 18,000 kg | |
Curb Weight | 8,305 kg | |
Rated Load | 9,565 / 9,500 kg | |
Wheelbase | 4,500 mm | |
Axle Count | 2 | |
Max Speed | 110 / 89 km/h | |
Engine | Multiple diesel options 162–220 kW (220–299 PS), GB17691-2018 National VI | |
Fuel Type | Diesel | |
Cabin Seating | 3 passengers (front row) | |
Suspension | Multi-leaf springs | |
Tires | 6 tires, 10.00R20 18PR / 295/80R22.5 18PR / 12R22.5 18PR / 11.00R20 18PR | |
Steering | Directional steering wheel |
