FEATURES
Robust Safety & Compliance Features
Methanol Ethanol Tank Truck is engineered with top-tier safety to meet strict hazardous goods transport standards. Classified as FL-type, Methanol Ethanol Tank Truck supports media with a maximum density of 780 kg/m³, including methanol and ethanol. Key safety highlights include front disc brakes, an exhaust system mounted at the front, and a speed limiter capped at 80 km/h to mitigate risks. Equipped with EBS3 from ZF Commercial Vehicle Systems and a tire blowout protection device for steering wheels, Methanol Ethanol Tank Truck ensures stable braking and handling. The rear axle adopts air suspension, while side/rear protections made of Q235 steel enhance structural safety. A GPS-enabled driving recorder and mandatory reflective markers further boost operational safety.
High-Capacity & Durable Tank Design
Boasting a total tank capacity of 20 m³ and effective volume of 19.2 m³, Methanol Ethanol Tank Truck balances large load capacity with reliable performance. The tank of 20cbm methanol ethanol tank truck, crafted from 5.2mm-thick Q235 carbon steel, features advanced manufacturing processes: all main welds undergo X-ray inspection, ensuring leak-proof integrity via single-sided welding with double-sided forming technology. Sandblasting treatment removes rust and contaminants, followed by a three-step painting process (pre-installation + baking + final assembly) for uniform, long-lasting corrosion resistance. Standard configurations include two European-standard tank openings, a subsea valve, a chemical pump (left rear-mounted for easy loading/unloading), and safety components like a pressure relief valve and rupture disc (methanol-specific).
Powerful & Reliable Chassis Performance
Built on the SINOTRUK Shandeka ZZ1266N56CGF1K chassis, this Methanol Ethanol Tank Truck delivers robust power and durability for heavy-duty operations. It is powered by a MC07.25-60 engine (202kW/274HP) paired with an HW95508STCL transmission and HW45ZC power take-off, ensuring efficient power delivery with a fuel consumption as low as 32.15 L/100km. The 3-axle design with multiple wheelbase options (e.g., 1800+4400mm) and 295/80R22.5 18PR radial tires guarantees stability on diverse road conditions. The G5-M cab accommodates 2-3 passengers, with optional configurations for air tanks, fuel tanks, and battery positions. Backed by SINOTRUK’s official warranty, the chassis offers proven reliability, making it ideal for long-haul flammable liquid transport.
SPECIFICATIONS
BASIC INFORMATION | |
Product Model | Sitrak 20CBM Methanol Ethanol Tank Truck |
Overall Dimension | 10100x2540x3450 m |
Curb Weight | 10305 Kg |
GVW | 25500 Kg |
Front/Rear Overhang | 1450/2450 mm |
Cab Seating Capacity | 2-3 Persons |
CHASSIS | |
Chassis Model | SITRAK ZZ1266N56CGF1K |
Pay Load | 15000,15065 Kg |
Axle Configuration | 6×2 |
Wheel Base | 1800+4200 mm |
Tire | 295/80R22.5 |
Engine Brand | SITRAK |
Max. Speed | 80 km/h |
UPPER STRUCTURE | |
Media Type | Fuel Such as Diesel/Gasoline/Engine Oil |
Color | Customized |
Tank Material | Q235 Carbon Steel |
Tank Thickness | 4-6 mm (customizable) |
ABS | YES |
Equipments | Equipped with a chemical pump, with pump inlet and outlet on the left rear side, two European standard tank openings, one bottom valve, one tool box, two oil hoses, upper guardrails, two fire extinguishers, and a fireproof cover. (Designed for methanol medium, with dedicated methanol tank opening, safety valve, bursting disc, and vacuum valve.) |
