FEATURES
Vehicle logistics transportation
Double Decker Car Carrier Semi Trailer for mass delivery of new cars to automobile manufacturers and 4S dealerships, as well as transshipment and redistribution of finished vehicles between cities.
Inter-provincial transfer of used cars
Double Decker Car Carrier Semi Trailer enables cross-regional distribution and long-distance transport of large volumes of used cars, effectively lowering the transportation cost per vehicle.
Long-distance trunk logistics
Double Decker Car Carrier Semi Trailer is suitable for centralized consignment of large batches of vehicles over long distances on main highways and inter-provincial trunk routes.
Batch distribution for automobile enterprises
Double Decker Car Carrier Semi Trailer enables mass delivery of vehicles to auto manufacturers, warehouse transit, and internal vehicle scheduling inside industrial parks.
Engineering & special vehicle transportation
The Car Carrier Semi Trailer enables centralized transport of compact SUVs, family sedans, and light commuter vehicles, with strong universal applicability.
SPECIFICATIONS
Product | Double Decker Car Carrier Semi Trailer |
| Overall Dimension | 13750×3000×3500 mm(customized) |
Curb Weight | 6980,6700 kg |
Fifth Wheel | 16000 kg |
Wheelbase | 7360+1310+1310 mm |
| Growss Vehicle Weight | 40000 kg |
Chassis Detail | |
Axle | 3 |
Axle Load | 24000 kg x 3 |
Suspension | -/10/10/10,-/8/8/8 Leaf Springs(customized) |
Tire Specifications | 8.25R20 16PR |
Number of Tires | 12 |
Upper Body Detail | |
Protection Material | Q235 Carbon Steel |
Rear protection ground clearance | 500 mm |
Trailer Type | Flatbed |
ABS | HNABS – 4S/2M |
