FEATURES
Heavy Duty Enclosed Structure
This Box Semi Trailer adopts a heavy duty frame and enclosed body structure, providing strong loading performance and reliable durability for long-distance cargo transport. The reinforced chassis and box body are designed to handle demanding freight tasks while maintaining stable operation on different road conditions.
Stable 3-Axle Configuration
The 3-axle design improves load distribution, driving stability, and road adaptability under heavy-duty logistics conditions. Semi Trailer is suitable for high-payload freight transport, long-distance delivery, and frequent commercial operation.
Enclosed Cargo Body for Better Protection
As an Enclosed Cargo Trailer, the fully closed box-type body helps protect goods from rain, dust, sunlight, and road debris during transportation. This enclosed design is especially suitable for packaged goods, industrial products, and general cargo that require cleaner and safer transport conditions.
Flexible Box Type Semi Trailer Options
This Box Semi Trailer is available with multiple lengths and payload configurations, offering practical solutions for general cargo, packaged goods, industrial materials, and freight logistics. Different size options allow customers to choose a suitable trailer configuration according to cargo volume, loading requirements, and transport routes.
SPECIFICATIONS
| Parameter | Specification |
| Product Model | Box Semi Trailer |
| Color | Customizable |
| Over Dimension(L×W×H) | 13750×2500×4000 mm |
| Cargo Box Dimension (L×W×H) | 13600×2450×2890 mm |
| GVW | 40000 Kg |
| Payload | 31500 Kg |
| Curb Weight | 8500 Kg |
| Wheelbase | 7,300/1,310/1,310 mm |
| Rear Suspension | 2250/2080/2050 mm |
| Departure angle | 12, 13, 14° |
| Axle | 3 |
| Axle Load | 24000 Kg |
| Tire Specifications | 11R20 12PR |
| Number of tires | 12 |
The above mentioned figures are approximate.
