FEATURES
Dual Wing Opening Design
The 85CBM Wing Opening Semi Trailer features side-opening wings on both sides, allowing quick and complete access to the cargo area. This design helps improve loading efficiency, especially for palletized goods, packaged cargo, and warehouse distribution.
Robust & High-Capacity Construction
Built with high-strength materials, this trailer supports heavy loads while maintaining structural integrity during long-distance transport. The reinforced frame is designed for demanding freight operations and frequent commercial use.
3-Axle Stability
Equipped with a 3-axle configuration, the semi trailer ensures balanced weight distribution and superior stability, making it safe and dependable even when transporting bulky or oversized cargo.
Spacious 85CBM Cargo Volume
With a generous cargo box volume of 85CBM, the wing opening semi trailer accommodates large shipments and palletized goods, maximizing transport efficiency and operational productivity.
Versatile Logistics Solution
Ideal for dry van and cargo transport, this Wing Opening Semi Trailer is suitable for a wide range of industries, offering a flexible and reliable solution for various freight operations.
SPECIFICATIONS
| Parameter | Specification |
| PRODUCT MODEL | Wing opening Semi trailer |
| Color | Customizable |
| Over Dimension(L×W×H) | 13750 × 2550 × 4000 mm |
| Cargo Box Dimension (L×W×H) | 13600 × 2470 × 2600 mm |
| GVW | 40,000 kg |
| Payload | 32,150 kg |
| Curb Weight | 8500 kg |
| Wheelbase | 7,300/1,310/1,310 mm |
| Rear Suspension | 2250, 2080, 2050 mm |
| Departure angle | 12, 13, 14° |
| Axle | 3 |
| Axle Load | 24,000 kg |
| Tire Specifications | 12R22.5 12PR |
| Number of tires | 12 |
The above mentioned figures are approximate.
