High-Capacity 18 Ton Electric Road Sweeper Truck for Municipal Cleaning
The 18 Ton Electric Road Sweeper Truck is designed for high-efficiency urban sanitation and large-scale road cleaning operations. Built on a durable CLW chassis with a 5000 mm wheelbase, the vehicle offers excellent stability, load capacity, and reliability during daily municipal cleaning work.
With a gross vehicle weight of 18,000 kg and an optimized structural design, this electric sweeper truck can operate efficiently on urban roads, highways, airports, logistics parks, and industrial zones. The overall dimensions of 8930 × 2550 × 3150 mm provide a balanced structure for maneuverability while maintaining a large cleaning system.
The vehicle features a large sweeping width of 3–3.5 meters, allowing it to cover wide road surfaces quickly. With a maximum sweeping capacity of up to 50,000 m³/h, this road sweeper can remove dust, sand, leaves, and debris effectively, significantly improving cleaning efficiency for municipal sanitation departments.
Powerful Electric Drive with 281.9 kWh CATL Lithium Battery
As a modern New Energy Road Cleaning Truck, this model adopts a high-performance CATL (Ningde Times) lithium iron phosphate battery system with a total capacity of 281.9 kWh. This advanced battery technology ensures long working hours, high safety standards, and stable energy output for sanitation operations.
The main drive motor provides 175 kW continuous power and up to 265 kW maximum power, ensuring strong performance even when operating on slopes or during heavy cleaning tasks. Optional configurations are available for higher power outputs depending on operational requirements.
The vehicle also supports fast charging with a single charging port, allowing the battery to reach full capacity in approximately 2.5 hours. Compared with traditional diesel sanitation trucks, this Electric Street Cleaning Vehicle significantly reduces fuel consumption, maintenance costs, and emissions, making it an ideal solution for environmentally friendly urban sanitation systems.
Efficient Sweeping and Dust Collection System
The 18-Ton Electric Road Sweeper Truck is equipped with a highly efficient sweeping and suction system designed to deliver outstanding cleaning performance. The integrated system combines powerful brushes, strong suction airflow, and an optimized dust filtration system to remove various types of road debris.
The vehicle has an 8 m³ dust collection tank and an 8 m³ water tank, providing sufficient capacity for long cleaning operations without frequent unloading. The high-efficiency suction system can handle particles with a suction density of up to 2 g/cm³ and debris sizes larger than 100 mm, ensuring that even heavy debris can be effectively collected.
With a cleaning efficiency of over 96%, the vehicle ensures that road surfaces remain clean after a single pass. The maximum suction capacity of 50,000 m³/h provides powerful dust removal capability, making the truck highly suitable for city streets, construction areas, and industrial parks where dust control is critical.
Efficient Sweeping and Dust Collection System
The 18-Ton Electric Road Sweeper Truck is equipped with a highly efficient sweeping and suction system designed to deliver outstanding cleaning performance. The integrated system combines powerful brushes, strong suction airflow, and an optimized dust filtration system to remove various types of road debris.
The vehicle has an 8 m³ dust collection tank and an 8 m³ water tank, providing sufficient capacity for long cleaning operations without frequent unloading. The high-efficiency suction system can handle particles with a suction density of up to 2 g/cm³ and debris sizes larger than 100 mm, ensuring that even heavy debris can be effectively collected.
With a cleaning efficiency of over 96%, the vehicle ensures that road surfaces remain clean after a single pass. The maximum suction capacity of 50,000 m³/h provides powerful dust removal capability, making the truck highly suitable for city streets, construction areas, and industrial parks where dust control is critical.
SPECIFICATIONS
| Item | Specification |
|---|---|
| Model | 18-Ton Electric Road Sweeper Truck |
| Chassis Brand | CLW |
| Overall Dimensions | 8930 × 2550 × 3150 mm |
| Wheelbase | 5000 mm |
| GVW | 18,000 kg |
| Curb Weight | 12,950 kg |
| Tank Capacity | 8 m³ Water Tank / 8 m³ Dust Tank |
| Effective Tank Volume | 2500 L |
| Sweeping Width | 3 – 3.5 m |
| Sweeping Speed | 5 – 15 km/h |
| Cleaning Speed | 15 – 20 km/h |
| Maximum Sweeping Capacity | 50,000 m³/h |
| Cleaning Efficiency | ≥96% |
| Operating Noise | <88 dB |
