FEATURES
Premium Cab Comfort and Ergonomics
The cabin is designed for operator comfort and efficiency, featuring air-suspension seating, electric windows, multifunction steering wheel, MP5 multimedia system, electric tilting, and factory-installed air conditioning. These features reduce driver fatigue, improve safety, and enhance control during long working hours. The ergonomically designed cab ensures smooth operation of the 10-16 ton truck mounted crane, making it ideal for heavy lifting tasks.
Powerful Engine and Transmission Options
Equipped with advanced diesel engines ranging from 350 to 400 HP, coupled with 10- or 12-speed gearboxes, this heavy duty crane truck provides outstanding torque, fuel efficiency, and smooth acceleration even under maximum load. The robust drivetrain ensures reliability across tough construction environments, enabling operators to lift 10-16 ton loads safely and efficiently.
Reinforced Chassis and Suspension
Built with a multi-layer reinforced frame and high-capacity axles (5-ton front, 10-13 ton rear), this truck mounted crane is engineered for stability and durability. Steel radial tires provide excellent grip and long service life, while the optional upgrades offer enhanced load-bearing capability. A 400L aluminum fuel tank and reinforced air tanks ensure operational continuity on large-scale projects.
Versatile Crane Options and Cargo Capacity
The truck mounted crane can be configured with 10-16 ton lifting capacity from top crane manufacturers, featuring multiple reach options for flexible operations. The cargo bed dimensions and adjustable axle configurations accommodate diverse loads and project requirements. This combination of lifting capability and cargo versatility makes it an essential tool for construction, industrial, and logistics applications.
SPECIFICATIONS
| Item | Specification |
|---|---|
| Cabin Features | Air-suspension seat, electric windows, multifunction steering wheel, MP5 multimedia system, electric tilting, factory-installed air conditioning |
| Engine Options | 350 HP diesel engine / 400 HP diesel engine (customizable) |
| Transmission | 10-speed / 12-speed gearbox |
| Front Axle | 5-ton |
| Rear Axle | 10-ton (optional 13-ton upgrade) |
| Chassis Frame | Reinforced multi-layer frame (300mm 8+6+6 structure) |
| Tires | 11.00R20 steel radial tires |
| Fuel Tank | 400L aluminum |
| Air Tanks | Aluminum air tanks |
| Battery | Heavy-duty battery |
| Brake System | High-performance brake valve |
| Overall Dimensions (L×W×H) | 12,000 × 2,550 × 3,950 mm |
| Cargo Bed Dimensions (L×W×H) | 8,500 / 8,300 × 2,480 × 800 / 600 mm |
| Wheelbase | 2,250 + 4,350 + 1,350 mm |
| Crane Options | 10-16 ton lifting capacity (from top manufacturers, multiple reach configurations) |
| Optional Upgrades | Engine: 350 HP / 400 HP, Transmission: 12-speed, Rear axle: 13-ton |
